Model: Sendary-PWMSCDROE-500L/h、Sendary-WFI4-200L/h
500L/h purified water equipment + 200L/h injection water equipment
500L/h purified water equipment + 200L/h injection water equipment
500L/h purified water equipment + 200L/h injection water equipment
500L/h purified water equipment + 200L/h injection water equipment
500L/h purified water equipment + 200L/h injection water equipment
Product Overview
Water for injection equipment adopts advanced two-stage RO+RO, EDI and multi-effect distillation process, and the water quality meets the standards of Chinese, American and European Pharmacopoeia and GMP, FDA and other certification requirements; Humanized design, modular installation, small floor area, stable operation, one-touch start, easy operation and maintenance, high efficiency and energy conservation.
Specification
Product water quality Complies with Chinese Pharmacopoeia 2020, USP39, European Pharmacopoeia EP8.0
Product process Pretreatment+double reverse osmosis (RO+RO)+electrodeionization (EDI)+four-effect distillation
Mode of disinfection Superheat water disinfection
control mode Fully automatic control
Remarks: The system is customized according to user requirements (URS); All the pictures and videos displayed are the product cases of Carryclean Company.
Performance introduction
  • Design Criteria

    As per the latest Chinese, American and European Pharmacopoeia standards

    Design required to comply with cGMP and GAMP specifications,,

    Compliance with GMP, FDA certification requirements


  • 3D simulation design

    3D analog manufacturing installation,

    Customers participate in the whole process, and the detailed effects are displayed in advance, so as to guarantee the customer's needs in all aspects。

  • Integrated design

    Modular design: more compact structure, simpler operation and maintenance。

  • Design according to URS

    Comprehensively understand the customer's requirements for product specification, product process, system configuration, etc. Customized design

Process flow of purified water equipment

Optional disinfection methods: activated carbon pasteurization, CIP cleaning system, ozone sterilization of distribution system, pasteurization of distribution system and pure steam sterilization of distribution system.

Remarks: Sendary Water system is customized according to user requirements (URS)

系统特点
  • 制造:

    选择优质原材料,用专业仪器设备来料严格质检;

    模块化3D设计,按图施工;

    管道连接方式优先采用焊接,其次卡箍连接,控制微生物的滋生;

    采用轨道自动焊机,焊接后20%内窥镜检测,人工焊接100%内窥镜检测;

    现场施工之前先进行安装规范培训,再施工。

  • 品质:

    在线监测产水水质符合客户需求;

    系统设计使用寿命是安全稳定运行15年;

    提供GMP咨询服务和GMP验证体系文件;

    系统最大限度减少微生物滋生风险,死角小于3D要求;

    排水采用的是空气阻断的方式,避免倒吸及交叉污染,设最低点排放及5‰坡度;

    循环管道回水流速大于1m/s,控制微生物滋生

    二级浓水、EDI浓水、不合格纯化水返回到原水罐合理回用,节约原水用水量,降低后期运营成本。

  • 安全:

    具有三级管理权限,依次为操作员、管理员、高级管理员。每个登录帐号,有相应的登录密码(密码可修改),系统5分钟后自动注销,防止未授权人员进入系统误操作,参数可恢复出厂设置;

    在系统关键的地方设置过载、高压、低压保护,所有故障、警报系统自动记录;

    控制线路采用24V安全电压,确保操作人员和设备的安全

    多方内部通讯系统,在任意层的工作站点,均能相互浏览运行状态;

    系统发生故障将短信通知对方,并能实现手机物联,观察运行状态。

  • 操作:

    融入人机工程学设计,触摸屏、开关、仪器、仪表、取样等位置的高度,符合国人平均身高操作;

    一键式启动,操作、维护简单方便;

    特殊设备具有操作平台及安全护栏。

Service
  • Comprehensive service of water system

    Provide full-process services including system design consulting, system equipment, GMP verification consulting, upgrading and renovation, operation and maintenance, etc.

  • Verification consulting services

    Provide GMP, FDA verification consulting and system DQ, FAT, IQ, QQ, SAT, PQ verification data

  • Three-dimensional service

    Pre-sale: URS demand analysis

    During sale: design, installation, debugging, verification, training

    After-sales: rapid response, long-term service

  • Tailored as needed

    Comprehensive understanding of customer needs for product specifications, product processes, system configurations, etc. Tailored design


GMP Verification Service
Verification data:
GMP project process:
GMP Services:

Provide complete GMP system validation documents.Professional validation services throughout the project;

>Free installation provides users with all the necessary conditions and work support for FAT testing;

>Provide users with free DQ, FAT, SAT, Q, OQ, PQ verification documents required for equipment;;

International standards, in line with the requirements of the Chinese Pharmacopoeia, the European Pharmacopoeia, the British Pharmacopoeia, FDA, etc.;;

Striving for rich experience can avoid unnecessary design defects for you;

High efficiency work can shorten the project cycle for you;

>Provide users with guidance and related technical services during the installation of equipment for free;

>Provide free on-site equipment debugging for users to ensure that the equipment quality and related technologies meet contract requirements until the user completes SAT well acceptance and delivery for use;

>Free technical operator training for users until they are familiar with equipment and process technology and have the ability to independently operate, maintain, and repair the equipment (establish and provide SOP documents for customers)。

Service Commitment
Training Services

1. Train 1-2 equipment operation and management personnel to participate in the entire process of on-site installation to ensure that operators fully understand the equipment process principles.

2. Provide systematic technical information documents and comprehensive training, guide the completion of standardized operation procedures (SOP), establish operational inspection processes and systems.

3. After training, both practical and theoretical examinations will be conducted.  A score of 90 in theory and 100 in practical operation is considered as passing the examination.  Only those who pass the examination can take up their posts.

4. Provide updates and upgrades of equipment technical data and training materials as needed.

5. According to the operation and management personnel's use of equipment, they can receive targeted refresher training at Kerui Company.


After-sales service

1. After receiving the notification of equipment failure maintenance, propose a solution within 30 minutes and provide on-site service within 72 hours.

2. The equipment design, manufacturing, verification, and operation data are carefully preserved for 15 years, and a customer-specific file is established for easy access at any time, enabling traceability for equipment managers.

3. Set up a customer file management center,where after sales professionals can update。

4. After-sales professionals proactively conduct telephone follow-ups, record relevant data, and professional engineers review the data.If there are any issues, they will communicate and resolve them in a timely manner, and provide methods to reduce operating costs, reminders on maintenance and consumables replacement, and other related matters at any time.

5. The equipment is provided with vulnerable spare parts, and the company's warehouse is well stocked with commonly used consumables and accessories.Maintenance parts and materials are provided to the site for problem handling in the first time, and commonly used consumables and accessories are delivered to the site within 5-7 days.
